TSS SERIES CAM CLUTCH

TSS SERIES CAM CLUTCH

TSS SERIES CAM CLUTCH

Add to Query Cart

Send Enquiry Share

Description

  Dimensions and Capacities Dimensions in mm


TSS -Series
Installation and Usage
1.
The TSS Series Cam Clutch is designed for press fit installation.
Correct interference dimensions must be maintained to obtain
maximum clutch performance.The internal diameter of the housing
should meet the H7 tolerance. Refer to item 3 in the installation and
usage of BB Series Cam Clutches for information on the
installation method.
2.

Make sure the housing has enough strength to withstand the

pressure required for the press fitting installation of the clutch.
3.

When installing the clutch, mount it with a type 62 bearing

to avoid radial force, since this clutch does not have any

bearings inside.
4.
 Confirm the direction of rotation before installation.
5.
The recommended shaft tolerance is H7, and the key
profile should be in accordance with the following standard.

TSS 8   ~ 12............DIN 6885.1
TSS 15 ~ 60............DIN 6885.3
6.

Suitable surface pressure of the key should be selected

according to your company design standards.

Lubrication
1.
Oil lubrication is recommended.
2.

Don not use greases or lubricants with EP additives.
